FRAME
Carbon HMF
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Range Extender Ready
TRAVEL
Front: 150mm / Rear: 155mm
FORK
Marzocchi Z2 Air Rail
3 modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 150mm travel
REAR SHOCK
FOX Float Custom EVOL Performace Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 155mm / T185X55mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
DRIVE UNIT
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BATTERY
TQ Internal 360Wh
DISPLAY
TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app
CHARGER
TQ 100-240V-4A
REAR DERAILLEUR
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-IR / Rapidfire Plus
I-spec EV clamp
CRANKSET
FSA Alloy crankset / 175mm / 34T
CHAINGUIDE
e*thirteen / e*spec Slider
CHAINRING
Scott custom spider / FSA 12Speed 34T chainring
CHAIN
Shimano CN-M6100
CASSETTE
Shimano CS-M6100 / 10-51 T
BRAKES
SRAM DB8 4 Piston Disc
ROTOR
SRAM Centerline CL Rotors F&R 200mm
HANDLEBAR
Syncros Hixon 2.0 Alloy 6061 D.B.
12mm Rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips
H’STEM
Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8″
SEATPOST
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm
S size 140mm / M size 180mm / L & XL size 210mm
SEAT
Syncros Tofino 2.0 Regular
HEADSET
Syncros – Acros Angle adjust & Cable Routing HS System
Stainless / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148M / 12x148mm
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
FRONT TIRE
Maxxis Dissector / 29×2.6″ / 60TPI Wire Bead
EXO
Dual
REAR TIRE
Maxxis Dissector / 29×2.6″ / 60TPI Wire Bead
EXO
Dual
APPROX WEIGHT IN KG
19.3 (with tubes)
APPROX WEIGHT IN LBS
42.55 (with tubes)
MAX. SYSTEM WEIGHT
128kg
