FRAME
ROGUE 29″ 6061 Aluminium FRAME
MODERN GEOMETRY / MACHINE FORMED TUBING / STANDARD 135mm QR 9mm REAR AXLE / DISC ONLY
FORK
SWOOP 330 MLO 100MM
29″ / 100mm / COIL SPRING / 9mm QR / MECHANICAL LOCKOUT
CHAINWHEEL
PROWHEEL TM-CY10 36-22T
PROWHEEL / 32T / 2 X 8 SPEED / ALLOY CRANK / STEEL CHAINRING / NO GUARD / S – 170mm CRANKARM / M+L+XL – 175mm CRANKARM
DERAILLEUR FRONT
SHIMANO 2 X 8
DERAILLEUR REAR
SHIMANO ALTUS RD-M310 2 X 8
SHIFTER LEFT
SHIMANO ALTUS SL-M315 2 X 8
SHIFTER RIGHT
SHIMANO ALTUS SL-M315 2 X 8
CHAIN
KMC Z7
FREEWHEEL
SHIMANO CS-HG318 11-34T
BB SET
FP-B602
SPEED
2 x 8 SPEED
BRAKE LEVER
TEKTRO
BRAKE FRONT
TEKTRO HD-M275 WITH 180mm ROTOR
BRAKE REAR
TEKTRO HD-M275 WITH 160mm ROTOR
BRAKE CABLE
BLACK
RIMS
TR COMP RIM
TR MD16 AL6061 36H 29″ MATT BLACK
HUB FRONT
ALLOY Q/R DISC BLACK
DC-1420, 14Gx28H, Q/R-M9x100x108mm
HUB REAR
ALLOY Q/R DISC BLACK
14G DC-1425, 8/9/10s, 14Gx28H, Q/R-M10x135x145mm
SPOKES
STEEL, ED BLACK 14Gx290mm / 14Gx288mm
TUBE
29\ A/V
TYRES
CHAOYANG VICTORY 29″ X 2.1″
CY H-5129 29″X2.1 27TPI WIRE BEAD BLACK WALL
GRIP
TR MTB GRIP
HANDLEBAR
TR COMP FLAT H/BAR 750mm
TR HB-M003 FLAT 750mm
HANDLEBAR STEM
TR COMP H/BAR STEM
TR SM-001 ALLOY OVERSIZED XS/S = 60mm / M/L = 80mm / XL = 100mm
HEADSET
FP-871, Ball retainer, Semi, ￠28.6×￠44×￠52mm
SPACER
10mm X 2 PCS
SADDLE
YBT-K245F041
SEAT POST
TR COMP 31.6mm
TR SP-003D RIGID ALLOY 31.6mm 350mm
SEAT CLAMP
PROMAX 327 Q
